Napoleon Vector 50 LV50 Linear Direct-Vent Gas Fireplace | LV50N-2 |


Free Shipping Tax Free Authorized Napoleon Dealer

Newly updated, the Napoleon Vector 50 is in a class of it's own. Customize the look with a trim kit or surround in traditional black or modern stainless steel. The multicolor LED lights which shine through the glass embers create endless display options through the full spectrum range. Control the flame height and lights using either the included remote or download the eFire app to your smart phone for access to even more options! The Vector 50 has some of the best features available today. Let us help you put together everything you need to complete your installation.

Vector Linear Gas Fireplace Brochure


  • See all available accessories here
  • Black Premium Clean Face Safety Barrier included
  • Remote Control and updated eFIRE bluetooth app included
  • Up to 36,000 BTU's
  • Available in Natural Gas and Propane
  • Standard NIGHT LIGHT system adds a gentle glow to the room
  • MIRRO-FLAME Porcelain Reflective Radiant Panels installed
  • Includes ember bed featuring multi-colored LED lights that accent from underneath
  • Divinity flame pattern provides heightened peaks and valleys
  • eFIRE Remote App - Total control of your fireplace from the convenience of your mobile device
  • Easy access air control for fast and precise air shutter adjustments
  • Fuel saving electronic ignition with battery back-up
  • Optional media includes: Nickel Stix, Mineral Rock Kit, Shore and Beach Fire Media Kits, Glass Ember Media and Glass Beads in various colors!


Napoleon Vector 50 LV50 Linear Direct-Vent Gas Fireplace | LV50N-2 | Technical Details


Product Details

Fuel Type: Gas
Vent Type: Direct Vent
Vent Size: 5x8
Ignition Type: Electronic
Installation Type: Zero Clearance
Style: Linear
Vent Inner Diameter: 5 Inches
Vent Outer Diameter: 8 Inches
Weight: 370 lbs.
Model: Natural Gas (NG) Propane (LP)
Max. (BTU/HR): 36,000 BTU's 32,000 BTU's
Min. (BTU/HR): 25,000 BTU's 30,000 BTU's
Napoleon Vector 50 LV50 Linear Direct-Vent Gas Fireplace | LV50N-2 | Dimensions


Actual Dimensions

Height Width Depth
413/16" 695/16" 197/8"

Framing Dimensions

Height Width Depth
3915/16" 6513/16" 201/8"

Technical Drawings

For more detail please see the Installation Manual

LV50 Technical Drawing 1
LV50 Technical Drawing 2


1. Am I required to purchase a surround with the fireplace?

No, the new Vector Series is designed as a clean face fireplace and includes the basic black safety barrier, you can choose an optional surround to fit your installation. These items are an additional cost due to the wide range of prices for the different options.

2. How will the fireplace be delivered? Will the delivery driver bring it into my house?

All fireplaces are delivered via freight (tractor trailer truck) to the specified street address you provide us, we do provide free lift gate service with all freight deliveries. The delivery driver is only responsible for unloading the items from the truck, not to move them anywhere. For more information on the delivery process visit our FAQ page.

3. The picture shows logs and stones, are those included?

The log and stone kits are optional accessories designed to enhance the look of your fireplace. You can find them and other media kits on the accessories page.

4. How is the fireplace vented?

The LV50 is typically vented using Napoleon's 5x8 venting components, you can find them here. We have assembled a complete vent kit for situations where the vent will have a short rise and turn to a horizontal termination (when the fireplace is installed on an exterior wall). If you need help designing the venting system let us know with an email or a phone call and we can assemble a custom solution for your situation.

5. Have another question? Feel free to chat, call, email or use the question and answer system below!

Questions & Answers

Ask a Question
  • What is the trim and what does it look like

    The trim is the decorative part that goes around the fireplace (think of a picture frame). You can scroll through the drop down for "See optional trim kit" and click on different options to see what they look like. Thanks for the question!

  • Does the lv 50 have led ligths included?

    Yes, the LV50 includes multi-color LED lights under the burner.  Thanks for your question!

  • Does the LV50N come with a battery backup?

    Yes, the LV50N includes a battery backup.  Thanks for your question!

  • What is the model number of the external blower unit that works with the LV50N as was discussed in the previous question? Thanks

    The external blower for the LV50 is the LHAD.  Thanks for your question!

  • Does this unit require a screen?

    Yes, the Vector series includes a safety screen in front of the glass.  The Luxuria series has a cool touch glass system if you prefer a model without the safety screen.  Thanks for your question!

  • I have an LV50 . Should I close the gas valve when the fireplace is not on? or leave it open all the time?

    The manual shut off valve is for service purposes not everyday use. Thanks for the question!

  • Does this fireplace come with a blower on it or can you purists blower with it

    Unfortunately, no, the Vector 50 doesn't have a blower nor is there an optional blower.  There is an optional heat distribution kit which is an external blower that pulls heat away from the fireplace via flexible duct.  The blower is mounted in the wall either near the fireplace or in another space.  Please let us know if you'd like more information.  Thanks for your question!
